| S e c t i o n MAINTENANCE
• PS air filter
Please, see Figure 7-1 Bottom view - Air Filters, Pos. (2).
- To remove the filter unscrew the 2 mounting screws (Figure 7-1 Bottom view - Air
Filters, Pos. (4)), while holding the bottom;
- Using a small flat screwdriver or tweezers gently lift the filter tray away from the
amplifier body.
Carefully clean the filters and covers from dust, wash them with tap water and leave them to dry up before
you mount them back.
Finally, mount the air filters in place in reverse order described above and fasten the screws tightly.
Figure 7-1 Bottom view - Air Filters
Figure 7-1 Bottom view - Air Filters
CAUTION
The air filter may be too dusty - be careful how you clean it so that you DO NOT INHALE
(BREATHE IN) neither spill the dust over! Wrap it, for instance, in a wet cloth before
cleaning!
