ALDI Ferrex Ninja User Manual

224cc 4 Stroke Petrol Lawn Mower
AFTER SALES SUPPORT
e-mail: info.aldi@positecgroup.com
1300 889 028
MODEL No.: SLM531 • 10/2020 • 10093
(toll free)
16
1. Upper handle bar
2.
Self Propel engage/disengage bar
3. Tool and refreshment holder
(2 x drink holders)
4. Cable holder clip/s
5. Upper handle locking lever (x2)
6. Upper handle locking knob (x2)
7. Self Propel engagement cable
8. Lower handle
9. Cutting height adjustment lever
10. Recoil starter
11. Engine
12. Air lter cover
13. Spark plug cover
14. Carry handle
15. Front wheels
16. Side ejector cover
17. Muer
18. Oil drain plug
19. Oil ller cap/dipstick
20. Rear wheels
21. Rotating quick adjustment
knobs (x2)
22. Rear discharge guard
23. Hard catcher
24. Key start battery system
charging cable
25. Recoil Starter handle holder
26. Key Set (x2)
27. Fuel tank cap
28. Fuel tank
29. Lower handle mounting plate
(with 3 height position)
30. Side discharge chute
31. Catcher attachment hook (x2)
32. Catcher attachment bracket (x2)
33. Deck wash nozzle
34. Mulching block
35. Air lter
36. 4 x Blades
37. Blade bolt
38. Outer Flange + washer
39. Spark Plug wrench
40. Blade mounting plate
41. Standard hose tting
42. Battery compartment
43. Battery charger adaptor
44. Plug Pack Charger
45. Battery release button
46. 20V Xnity Li-ion Battery
47. Spark Plug
Part List
Parts List

ALDI Ferrex Ninja Specifications

General

Brand	ALDI
Model	Ferrex Ninja
Category	Lawn Mower
Language	English
