224cc 4 Stroke Petrol Lawn Mower
e-mail: info.aldi@positecgroup.com1300 889 028
MODEL No.: SLM531 • 10/2020 • 10093
25
Preparing for Operation
1. Connect the battery charger adaptor (43) into
the plug pack charger (44). (Fig. F1)
2. Connect the plug pack charger (44) into the
240V mains power outlet. A “green” light
indicates power. (Fig. F2)
3. Slide the battery charger adaptor (43) onto
the 20V Xnity Li-ion battery (46) by aligning the
guiding rails. A click indicates the battery (46) is
tted. (Fig. F3)
4. The plug pack charger (44) light will change to “red”. The 20V Xnity Li-
ion battery (46) is now in the charging process. (Fig. F2)
When the light returns to “green”, the 20V Xnity Li-ion battery (46)
is fully charged.
NOTE: The power to the charger should be turned o when unattended,
with or without a battery inserted.
F3
Mulch and Mowing
Using the mower without the hard catcher (23)
attached, the lawn mower will mulch as it cuts and
and the ne grass clippings are distributed back
onto the grass surface without leaving piles of grass
clippings.
WARNING: Ensure the engine is NOT
operating when undertaking this task.
1. Remove the hard catcher (23) by lifting the rear
discharge guard (22) and releasing the hard
catcher (23). (Fig. G1)
2. Lift the rear discharge guard (22), insert the
mulching block (34) into position, then release
and close the rear discharge guard (22). (The
mulching block (34) is correctly in place when
the circle tabs on the block click into place at
Preparing for Operation
G2
G1
