224cc 4 Stroke Petrol Lawn Mower
AFTER SALES SUPPORT
e-mail: info.aldi@positecgroup.com
1300 889 028
MODEL No.: SLM531 • 10/2020 • 10093
(toll free)
26
H3
L (LOW)
H (HIGH)
the bottom of the rear discharge chute. (Fig. G2)
3. Ensure the side ejector cover (16) is in the closed
position. (Fig. G3)
Do NOT use the side discharge chute (30) when
mulch and mowing.
Adding and Checking the oil
IMPORTANT: The engine of this lawn mower
is packed with NO OIL in the engine. Prior to
starting the engine, Oil MUST be added to the
sump of the engine.
Failure to add sucient oil will result in damage
to the engine which is NOT covered under the
warranty of the lawn mower.
On a new lawn mower, the engine needs to be
lled with 500ml of SAE 10W/30 engine oil. We
recommend Ferrex® Full Synthetic 4 Stroke Oil.
Each time the lawn mower is used, the oil level
should be checked and if low, add sucient oil
to ensure the oil level is to the full mark on the
dipstick.
1. Position the lawn mower on a at and level
surface. Clean the area directly around the oil
ller cap/dipstick (19).
2. Remove the oil ller cap/dipstick (19) by turning
approximately a quarter turn in an anti clockwise
direction and lift the cap (19) outwards. (Fig. H1
& H2)
3. Clean the oil ller cap/dipstick (19) with a clean
cloth, cleaning away any visual oil.
4. FOR A NEW LAWN MOWER, add 500ml of 4
stroke SAE 10W/30 engine oil.
5. Insert the oil dipstick (19) back and secure the oil
ller cap/dipstick (19) by turning approximately a
quarter turn in a clockwise direction.
H1
Preparing for Operation
G3
H2
