The headphones monitoring system lets you listen to
any selected input or output signal using stereo
headphones. The signal is selected by pressing a
channel
switch. This is referred to as PFL (Pre-
Fade Listen) as the signal is monitored before the
fader. This means that the fader has no effect on the
monitored signal and can be turned down to allow
signal checking before raising the level in the mix.
Only one channel can be monitored at a time. The
signal is heard in mono or stereo depending on the
source. Each input, effect and output channel can be
monitored. The headphones are quiet when all
switches are off. Raise the headphones level control
for comfortable listening level.
Tip We recommend that robust good quality
enclosed ear stereo headphones of 30 to 600 ohms
impedance are used to ensure signal clarity and
continued reliability.
LCD DISPLAY
This displays the console status and control setting
information. Different screens are displayed
depending on which select key is active. The display
is illuminated for viewing in dark conditions. Large
pictures and text is used for easy viewing during
performance.
Memory numbers display which
,
or
memory is active or scrolled.
Screen title bar displays which screen has been
selected on the select keys below.
Menu items are displayed on 3 lines of text
together with a pointer to indicate which item is
active. On some screens the associated status is
displayed.
Control title bar displays the function or channel
numbers associated with the soft controls.
Control value bar displays the values associated
with the soft controls.
Graphic area displays the soft control settings as
level bars, faders, EQ response curve, pictures or
large font text depending on which screen is active.
.
OUTPUT MODE INDICATORS
One of three indicators displays the current AB
output (amplifier) configuration to show which output
mix is routed to each amplifier. The configuration
can be changed using
.
•
Stereo PA
•
1 monitor + mono PA
•
2 monitors + ext. PA
SIGNAL METERS
The signal routed to each amplifier is displayed on a
10 bar peak reading led meter. These are post fader
and pre AB level control. These meters also display
the PFL signal when selected. Optimum reading is
around 0dB with occasional loud peaks at +6.
PFL ACTIVE INDICATOR
This red indicator lights when any channel
switch
is pressed. The pre fader channel signal is routed to
the headphones and to the signal meters in mono or
stereo depending on the source. The meters switch to
read PFL instead of the AB outputs.
