input balanced XLR pin 2 hot 2k ohm -55 to –8dBu
input balanced TRS jack >30k ohm -31 to +16dBu
unbalanced RCA phono >30k ohm -31 to +16dBu
out imp balanced TRS jack <75 ohm0dBu
out imp balanced TRS jack <75 ohm0dBu
unbalanced RCA phono 600 ohm-10dBV
out imp balanced TRS jack <75 ohm0dBu
out imp balanced TRS jack <75 ohm0dBu
slave out imp balanced TRS jack <75 ohm0dBu
main out balance XLR pin 2 hot <75 ohm+4dBu (
---
)
speaker out Neutrik Speakon
®
into 4 ohm minimum (
---
)
/012345/6
stereo TRS jack for 30 to 600 ohm headphones
in DIN 5 pin
out DIN 5 pin
)
D-connector 9-pin for personal computer serial port
Maximum output XLR +22dBu into 600 ohm
jack +18dBu into 2k ohm
phono +10dBu into 10k ohm
Converters 20 bit 128 times oversampling
DSP processing 24 bit, 56 bit busses
Sampling frequency 44.1 kHz
Dynamic range 91 dB 94dB A-weighted
Frequency response 20 Hz to 20 kHz +0/-1dB
Distortion < 0.01% THD + noise 1kHz +14dBu out
Crosstalk < -90dB 1kHz inter channel
Noise Measured 22Hz to 22kHz rms
Mic EIN -127dB referred to 150 ohm source
