Default
controls = Channel wet/dry balance
Insertion type effect (insert signal path)
Wet = How much signal is routed through the effect
Dry = How much signal is routed direct to LR
Individual controls for CH1 to 8, FX2
25 steps from 0 (all dry) to 99 (all wet)
controls
Up to 4 parameters for each effect
Refer to Effects table
type
1 of 40 named presets
Includes echo and modulation effects
0
Refer to table
Refer to table
controls = Channel effects sends
System type effect (send / return signal path)
How much signal is routed to the effect
Individual controls for CH1 to 8, FX2
25 steps from Off to 0dB
controls
Up to 4 parameters for each effect
Refer to Effects table
type
1 of 40 named presets
Includes reverb and echo+reverb effects
Off
Refer to table
Refer to table
controls = Channel aux sends
Individual controls for CH1 to 8, FX1, FX2
25 steps from Off to +6dB
Global selection of sends pre or post channel faders
Off
controls = Channel foldback sends
Individual controls for CH1 to 8, FX1, FX2
25 steps from Off to +6dB
Off
TRIM = Channel fader level trims
Individual controls for CH1 to 8, FX1, FX2
19 steps from -15dB to +6dB
= Enable or disable the trim function
Off or On
0dB
On
Positions mono signal between left and right in LR mix
Balances left and right stereo signal in LR mix
Individual controls for CH1 to 8, FX1, FX2
19 steps from
to
to
Off
(centre)
