Allen-Bradley 20A Installation Instructions

Rockwell Automation Publication 750-IN001P-EN-P - April 2017 143
Lift and Mount the Drive Chapter 3
8. Determine reach required and install the deck in position A or position
B. See the next section for details.
Adjust Roll-out Cart Reach
See Figure 92 and Figure 93 to adjust the reach of the roll-out cart.
Figure 92 - Reach Position A
M10 x 1.5
17 mm
78
(3.1)
