Rockwell Automation Publ
ication 750-IN001P-EN-P -
April 2017
51
Lift and Mount the Drive
Chapte
r 3
P
osition the Wiring Ba
y
T
o position the wir
ing bay
, follow these steps.
1.
Rem
ove
and
di
sca
rd the
scre
ws
that ho
ld
the pr
ote
cti
ve p
ane
l a
g
a
inst
the
left side of the wiri
ng bay
.
2.
Remove and d
iscard the protective panel.
M6 x 13
10 mm
IP54, NEMA 12 Enclosu
re Rating Shown
50
52
