Allen-Bradley 20A Installation Instructions

Rockwell Automation Publication 750-IN001P-EN-P - April 2017 39
Chapter 3
Lift and Mount the Drive
Drive Weights
All lifting equipment and components (hooks, bolts, lifts, slings, chains, and so
on) must be properly sized and rated to safely lift and hold the weight of the
drive.
Table 6 - Approximate Drive Weights – Wall Mount Frames 1…7 and Floor Mount Frames
8…10
ATTENTION: To guard against possible personal injury and/or equipment
damage, follow these guidelines:
• Inspect all lifting hardware for proper attachment before you lift the drive.
• Do not allow any part of the drive or lift mechanism to contact electrically
charged conductors or components.
• Do not subject the drive to high rates of acceleration or deceleration while
transporting to the mounting location or when lifting.
• Do not allow personnel or their limbs directly underneath the drive when it is
being lifted and mounted.
Drive Frame
Size
Drive Rating Enclosure Code/Weight, kg (lb)
kW (400V, 690V) Hp (480V, 600V) FGNR
Standard
(20F, 20G)
AC input
and common
DC input
1 0.75…7.5 1…10
6 (13)
2 0.75…11 1…15 8 (17) 8 (17) 8 (17)
3 15…22 0.5…30 12 (26) 12 (26) 12 (26)
4 30…37 20…50 14 (30) 14 (30) 14 (30)
5 45…55 30…70 20 (45) 20 (45) 20 (45)
6 5.5…75 75…100 37 (82) 89 (197) 37 (82)
45…132 50…200 38 (84) 91 (200) 39 (85)
7 132…200 150…300 69 (152) 135 (297) 79 (174)
200…270 300…400 96 (212) 162 (357) 106 (234)
B, L P, W J K, Y
Standard
(20G)
AC input 8 250…400 350…650 623 (1374) 1145 (2525) 644 (1419) 1166 (2570)
9 500…850 700…1250 1246 (2748) 2290 (5051) 1287 (2838) 2332 (5141)
10 900…1250 1350…1750 1869 (4122) 3435 (7576) 1931 (4257) 3498 (7711)
Common DC
input
8 250…400 350…650 566 (1248) 1088 (2400) 586 (1293) 1109 (2445)
9 500…850 700…1250 1132 (2497) 2176 (4799) 1173 (2587) 2218 (4889)
10 900…1250 1350…1750 1698 (3745) 3264 (7199) 1760 (3880) 3327 (7334)
With
options
(21G)
AC input 8 250…400 350…650 1145 (2525) 1675 (3694) 1166 (2570) 1696 (3739)
9 500…850 700…1250 1730 (3815) 2820 (6219) 1771 (3905) 2862 (6309)
10 900…1250 1350…1750 2315 (5106) 3965 (8745) 2377 (5241) 4028 (8880)
