Rockwell Automation Publ
ication 750-IN001P-EN-P -
April 2017
47
Lift and Mount the Drive
Chapte
r 3
Remove Drive Cabinet Lift
ing
Angle
After the driv
e cabinet is i
n its final position, re
move t
he lifting angle.
M12
67.8 N•m (600 lb•in)
18 mm
Floo
r M
oun
t Fram
e 8
Floo
r M
oun
t Fram
e 9
Floo
r M
oun
t Fram
e 1
0
46
