148
Rockwell Automation Publ
ication 750-IN001P-EN-P -
April 2017
Chapt
er 3
Lift and Moun
t the Drive
Cabinet Options As
sembly – Floor Mount Frames 9 and 10
T
o pull the drive asse
mbly on to the r
oll-out cart, slowly and sm
oothly pull the
hand
le
.
See
pag
e
134
for informa
tion on related electrical c
onnections.
