Allen-Bradley 5069-IB8S User Manual

224 Rockwell Automation Publication 5069-UM004A-EN-P - April 2019
Appendix A Troubleshoot Your Module
Status and Fault Information in Module Properties Categories
The Module Properties section in the Logix Designer application includes a
series of categories. The numbers and types of categories varies by module type.
Each category includes options to configure the module or monitor the status
of the module. The following are ways to monitor the state of a module for
faults:
•
Module Status on General Category
•
Module Fault Descriptions on Connection Category
•
Module Fault Descriptions on Module Info Category
Module Status on General Category
As shown in Figure 29, the status of a module is indicated on the General
category of the Modules Properties.
Figure 29 - Fault Message in Status Line
