32 Rockwell Automation Publication 5069-UM004A-EN-P - April 2019
Chapter 1 Digital Module Operation in a Control System
Remote I/O Modules
Complete the following:
1. Install a controller that is compatible with the remote Compact 5000
I/O digital modules to be used in the application via an EtherNet/IP
network.
2. Install an EtherNet/IP network.
3. Connect the controller to the network.
4. Install a Compact 5000 I/O EtherNet/IP adapter.
5. Connect the adapter to the network.
6. Install the Compact 5000 I/O digital modules to the right of the
adapter.
7. Install the end cap on the last module in the local system.
For information on how to install compatible controllers, adapters, and
Compact 5000 I/O modules, see the publications that are listed in
Table 2 on
page 14.
IMPORTANT Remember, you must use a Compact GuardLogix 5380 controller or
GuardLogix 5580 controller if the set of remote Compact 5000 I/O
digital modules include safety modules.
For more information on controller compatibility, see
Controller and
Software Compatibility on page 18.
IMPORTANT The end cap in a CompactLogix 5380, CompactLogix 5480, or
Compact GuardLogix 5380 control system covers the exposed
interconnection on the last module on the DIN rail.
If you do not install an end cap on the last module on the DIN rail,
equipment damage or injury can occur.
