Rockwell Automation Publication 2080-UM003A-EN-E - March 2013 3
Hardware Features Chapter 1
Double-width Expansion I/O
2085-IQ32T Hardware Features
1
1
45297
8
Front view
Right top view
45296
1
2085-OW16 shown
2
9
5
3
3
3
4
6
7
6
Module Description
Description Description
1 Mounting screw hole / mounting foot 6 Bus connector (male/female)
2 Removable Terminal Block (RTB)
(1)
7 Latch hooks
3 RTB hold down screws 8 I/O status LED
4 Cable grip 9 DIN rail mounting latch
5 Module interconnect latch
(1) The removable terminal block has slots for mechanical keying, to prevent inadvertently making the wrong
wire connections to your module. Expansion I/O modules are shipped with keys.
2
1
6
8
7
6
3
1
2
4
5
3
9
45927
Right top view
Front view
