Allen-Bradley Micro800 User Manual

4 Rockwell Automation Publication 2080-UM003A-EN-E - March 2013
Chapter 1 Hardware Features
Summary
This chapter included a brief introduction to the different analog and discrete
Micro800 expansion I/O modules and their hardware features.
2085-IQ32T Hardware Components
Description Description
1 Mounting screw hole / mounting foot 6 bus connector (male and female)
2 Connector 7 latch hooks
3 Connector retaining arm 8 I/O status LEDs
4 Cable grip 9 DIN rail mounting latch
5 Module interconnecting latch
