Page #15 background image
Micro850 24-Point Programmable Controllers 15
Publication 2080-IN007A-EN-P - September 2012
Specifications
General Specifications – 2080-LC50-24AWB, 2080-LC50-24QBB,
2080-LC50-24QVB, 2080-LC50-24QWB
Attribute 2080-LC50-24AWB 2080-LC50-24QWB 2080-LC50-24QVB 2080-LC50-24QBB
Number of I/O 24 (14 inputs, 10 outputs)
Dimensions
HxWxD
90 x 158 x 80 mm
(3.54 x 6.22 x 3.15 in.)
Shipping
weight,
approx.
0.423 kg (0.933 lb)
Wire size
Wiring
category
(1)
2 – on signal ports
2 – on power ports
2 – on communication ports
Wire type Use Copper Conductors only
Terminal
screw torque
0.4…0.5 Nm (3.5…4.4 lb-in.) using a 0.6 x 3.5 mm flat-blade screwdriver.
(Note: Use a handheld screwdriver to hold down the screws at the side.)
Input circuit
type
24V DC sink/source (standard and high-speed)
Output circuit
type
Relay 24V DC sink
(standard and
high-speed)
24V DC source
(standard and
high-speed)
Power
consumption
28 W
Power supply
voltage range
20.4…26.4V DC Class 2
I/O rating Input 120V AC 16 mA
Output 2 A, 240V AC,
2A, 24V DC
Input 24V, 8.8 mA
Output 2 A, 240V AC
2A, 24V DC
Input 24V, 8.8 mA
Output 24V DC, Class 2, 1 A per point
(Surrounding air temperature 30 °C)
24V DC, Class 2, 0.3 A per point
(Surrounding air temperature 65 °C)
Min Max
Solid
0.2 mm
2
(24 AWG) 2.5 mm
2
(12 AWG)
rated @ 90 °C (194 °F )
insulation max
Stranded
0.2 mm
2
(24 AWG) 2.5 mm
2
(12 AWG)
