18 Micro850 24-Point Programmable Controllers
Publication 2080-IN007A-EN-P - September 2012
Output Specifications
Attribute 2080-LC50-24QWB
2080-LC50-24AWB
2080-LC50-24QVB / 2080-LC50-24QBB
Relay Output Hi-Speed Output
(Outputs 0...1)
Standard Output
(Outputs 2 and higher)
Number of outputs 10 2 8
Output voltage, min 5V DC, 5V AC 10.8V DC 10V DC
Output voltage, max 125V DC, 265V AC 26.4V DC 26.4V DC
Load current, min 10 mA
Load current,
continuous, max
See Relay Contacts
Ratings on page 18
100 mA (high-speed
operation)
1.0 A @ 30 °C
0.3 A @ 65 °C
(standard operation)
1.0 A @ 30 °C
0.3 A @ 65 °C (standard
operation)
Surge current, per point See Relay Contacts
Ratings on page 18
4.0 A for 10 ms every 1 s @ 30 °C; every 2 s @
65 °C
(1)
(1)
Applies for general purpose operation only; does not apply for high-speed operation.
Current, per common, max 5 A – –
Turn on time/
Turn off time, max
10 ms 2.5 μs0.1 ms
1 ms
Relay Contacts Ratings
Maximum Volts Amperes Amperes
Continuous
Volt-Amperes
Make Break Make Break
120V AC 15 A 1.5 A 2.0 A 1800V A 180V A
240V AC 7.5 A 0.75 A
24V DC 1.0 A 1.0 A 28V A
125V DC 0.22 A
