Rockwell Automation Publication 750-RM003A-EN-P - April 2018 67
Chapter 2
Bus Supply Hardware and Parameter
Conversion
The PowerFlex 700AFE bus supply has limited I/O and control options. Most
of the available I/O options have equivalent PowerFlex 755T devices as
indicated in Table 32
.
See Specification and Feature Comparison
on page 33 for more information
about compatible PowerFlex 755T communication protocols and devices.
See the PowerFlex 750 TotalFORCE installation manual, publication 750-
IN100, for details of I/O and feedback option module terminal wiring and
specifications.
Configuration Software and
HIM Versions
There are several tools available for configuring PowerFlex 755T parameters.
You must use a compatible Human Interface Module (HIM) or configuration
software package to migrate to the new bus supply.
The 755TM bus supply uses similar HIMs and configuration software
packages as the PowerFlex 700AFE bus supply, but knowing the software
versions of each drive is essential to understand if the available software
packages are compatible.
Older configuration software tools do not support the PowerFlex 755T
product. We recommend that you use the latest available versions of software
configuration tools such as Studio 5000 Logix Designer application, RSLogix™
5000 software, or Connected Components Workbench™ software for full
featured configuration capabilities.
• Connected Components Workbench (CCW) can configure
PowerFlex 755T product parameters directly via EtherNet/IP
connection from your computer to the PowerFlex 755T product
Embedded or option module EtherNet/IP communication port.
Table 32 - I/O Comparison
Device or Function PowerFlex 700AFE PowerFlex 755TM Bus Supply
Digital and Analog I/O (s)
6 x digital input
3 x digital output
2 x analog input
2 x analog output
(o) 20-750-2262C-2R
(1)
(1) The 20-750-2262C-2R option module only has two relay outputs. If three relay outputs are required to match the PowerFlex
700AFE on board I/O, then another or additional I/O option module may be required for the PowerFlex 755TM bus supply.
