Installation
1
CAUTION
Do not block the unit's heat sink, thus preventing air circulation. If
blocked, heat will accumulate inside the unit and may cause a re.
The main unit must be mounted within 30 degrees of the
horizontal plane, back to front.
For details on how to install or remove CDE-W235EBT/CDE-W233E,
consult your Alpine dealer.
Heat sink
Less than 30°
Mounting the Microphone
(CDE-W235EBT only)
For the sake of safety, mount the microphone in the following location.
Choose a location for the microphone that can easily pick up the
driver’s voice. Requiring the driver to move towards the microphone for
audibility causes a distraction that could be dangerous.
•
•
•
In a stable and secure location.
In a location that does not inhibit safely driving the vehicle.
Mount the microphone in a location where the driver’s voice can
easily be picked up.
32
-EN
*
e illustration is for CDE-W235EBT.
To Next Page
