NXA-CFSP Compact Flash
7
MVP-7500/8400 Modero Viewpoint Wireless Touch Panels
NXA-CFSP Compact Flash
Overview
Every MVP panel is shipped with a 64 MB Compact Flash card.
Compact Flash Card - Security
All security user names and passwords (for the docking station) are stored in the Compact Flash card.
After installing the Compact Flash card upgrade, all security user names and passwords need to be re-
entered to enable security. For this reason, it is recommended that you upgrade the card prior to setting
up the security information for the docking station.
The NXA-CFSP Compact Flash card is factory programmed with panel firmware and can be upgraded
up to 1GB:
Installing the NXA-CFSP Compact Flash Card
Accessing the MVP’s Internal Components
1. Remove all connectors, remove power and remove batteries.
2. Remove the two housing screws (FIG. 5).
3. Grasp the bottom rim of the rear housing just above the MVP interface connector, and carefully pull
the bottom rim away from the IR Emitter and up, to expose the internal components.
4. Remove the trim from the top rim of the circuit board (FIG. 5).
Optional Compact Flash Upgrades
• NXA-CFSP128M - 128 MB Compact Flash card (FG2116-36)
• NXA-CFSP256M - 256 MB Compact Flash card (FG2116-37)
• NXA-CFSP512M - 512 MB Compact Flash card (FG2116-38)
• NXA-CFSP1G - 1 GB Compact Flash card (FG2116-39)
Batteries should be removed prior to upgrading the Compact Flash card.
