UDM-0808-SIG 8x8 Signature Series Multi-Format Distribution Hub
2
UDM-0808-SIG, UDM-RX02N and UDM-ABB-8-SIG Operation /Reference Guide
Product Specifications
UDM-0808-SIG Specifications
Power Requirements: • 3 PIN IEC, 100 to 240Vac 50/60Hz
• Dissipation: 130W
Front Panel Components
LEDs • Power Status bar - Blue light bar on front panel indicates unit is powered.
• Status LEDs - Eight blue LEDs light to indicate which of the eight outputs are
currently routing video to a connected UDM-RX02N Receiver.
Rear Panel Components
UDM Output Ports (1-8): Eight RJ45 ports provide connectivity to up to 8 UDM-RX02N receivers via Cat5/
5e/6/7.
A/V Source Input
Connectors (A-H):
Eight sets of Input connections for up to 8 A/V inputs with the following connectors:
• Video (see Video Inputs below)
• Analog audio Left / Right (see Audio Inputs below)
• SPDIF digital audio (see Audio Inputs below)
Video Inputs: HD15 female connector supports the following formats:
•VGA
• Component - requires an UDM-HD15RCA3 Breakout Cable (FG-HD15RCA3,
not included)
• S-Video - requires an UDM-SVID01 HD15 to SVideo cable (FG-UDM-SVID01,
not included)
• Composite - requires an UDM-HD15RCA3 Breakout Cable (FG-HD15RCA3, not
included)
• Max Video Input:
• 8 x RGBHV (or)
• 8 x S-Video (or)
• 8 x component (or)
• 24 composite inputs
Audio Inputs: • Analog Audio In - RCA female analog audio connectors (white = Left, red =
Right).
• SPDIF Audio In - RCA female digital audio connector (black).
NETWORK Port: RJ45 Ethernet port provides 100 BaseT network connectivity.
SERIAL Port: RJ12 port allows an administrator to receive debugging and diagnostic information
via RS232.
Note: Serial Interface: 115200, 8, N, 1
CASCADE Ports
(1-4 / 5-8):
• Cascade Out and In ports send and receive cascaded A/V signals to other UDM-
0808-SIG Hubs.
• The Cascade Out ports also provide audio-only to an
UDM-ABB-8-SIG Audio Breakout Box.
Note: Depending on the application, up to four UDM-0808-SIG Hubs can be cas-
caded together.
IEC Power Connector: Universal switch-mode power supply.
• As a Class 1 appliance the Hub should be connected to a mains supply with a
protective earthing connection.
• On/Off switch is located beside the power connector.
Note: The rating label found on the bottom left of the rear panel (beneath the IEC
connector) contains important information applicable to the Hub’s installation envi-
ronment.
Operating
Environment:
• 35°F to 95°F (5°C to 35°C)
• Max. relative humidity - 85% (non-condensing)
