UDM-0808-SIG, UDM-RX02N and UDM-ABB-8-SIG Operation /Reference Guide
UDM-0808-SIG WebConsole
Overview
UDM-0808-SIG hubs have a built-in WebConsole that allows you to make various configuration settings via a
web browser on any PC that has access to the Hub. The web console consists of a series of web pages that are
collectively called the "Configuration Manager" (FIG. 14).
Determining the IP Address of the UDM-0808-SIG
UDM-0808-SIG hubs feature a built-in zero-configuration networking client that allows you to determine the
unit’s IP address via Bonjour or a similar zero-configuration client. Zero-configuration (or Zeroconf, also
known as "Bonjour") technology provides a general method to discover services on a local area network. In
essence, it allows you to set up a network without any configuration, as described below.
Bonjour (Zero-Configuration) Client
You will need a zero-configuration client to determine the IP address of the UDM-0808-SIG. There are many
zero-configuration clients available. However, for the purposes of this document, we will refer to Bonjour for
Windows. It is free and widely available for download.
If you don’t already have it installed on your PC, download and install Bonjour for Windows before you begin.
1. With Bonjour for Windows running on a PC that has access to the LAN that the UDM-0808-SIG resides
on, connect the Hub to the network (see the UDM-0808-SIG Wiring and Connections section on page 5).
2. In Bonjour, you will see the UDM-0808-SIG join the network at power up.
3. In Bonjour, double-click on the UDM-0808-SIG link to access the selected unit's Configuration Manager
(IP Settings page).
4. The unit’s IP Address is displayed in the IP Settings page (FIG. 15).
At this point you can assign a new IP Address if necessary.
FIG. 14 Configuration Manager - IP Settings Page (initial view)
Click here to log in
Hover mouse here to access
the Admin drop-down menu
The UDM-0808-SIG is set to DHCP by default.
