14.22. Run Capacitor
It is mounted on the rear foot piece by means of snap-in tabs. If it is required to be removed, tabs of
the relevant part should be loosened from bottom and the piece should be pulled upwards to release it
from the tabs.
14.23. Filter Box
Filter piece is connected on the rear foot with a screw at one side and tab on the other. When it is
required to be removed, screw is unscrewed and then tab connection is released to detach the part.
Relevant part is serviced together with the supply cable.
14.24. Thermic Relay Group
Relay, which is one of the electrical components, is located in the terminal assembly.
To remove the related part, terminal box which is located on the compressor shall be removed (2), and
the grounding cable on the rear foot shall be removed with the help of a phillips screwdriver (3). All
sockets connected on the terminal box shall be removed (4). Screw connections shall be unscrewed
and the part can be removed as seen in the picture (5).
