ASROCK PHANTOM GAMING 4 B550 User Manual

B550 Phantom Gaming 4
7
English
1.3 Motherboard Layout
DDR4_A2 (64 bit, 288-pin module)
DDR4_A1 (64 bit, 288-pin module)
DDR4_B2 (64 bit, 288-pin module)
DDR4_B1 (64 bit, 288-pin module)
ATX 12V1
ATXPWR1
PCIE3
HDLED RESET
PLED PWRBTN
PANEL1
1
USB_3_4
1
1
SPK_PLED1
1
HD_AUDIO1
PCIE1
RoHS
12
15
19
2
Hyper M.2
PCIe Gen4 x4
CMOS
Battery
PCIE2
14
9
USB3_7 _8
10
SATA3 _6
SATA3 _5
SATA3 _4
SATA3 _3
CLRCMOS1
1
M2_2
M2_WIFI_CT1
M2_3
C 7
C 6
C 5
3
PCIE4
T
T
T
AUDIO
CODEC
SUPER
I/O
13
20
22
2324
30
21
6
5
CHA_FAN3/WP
CHA_FAN1/WP
CPU_FAN2/WP
ATX 12V2
CPU_FAN1
4
1
18
ADDR_LED1
1
RGB_LED1
1
28
ADDR_LED2
1
RGB_LED2
1
7
8
31
CPU
DRAM
VGA
BOOT
USB 3 .2 Gen1
T: USB3_1
B: USB3 _2
Top:
RJ-45
USB 3.2 Gen1
T: USB3_5
B: USB3_6
PS2
Keyb oard
/Mou se
Top:
LINE IN
Center:
FRON T
Bottom:
MIC IN
USB_1_2
1
29
C 8
T
SOCKETAM4
17
16
SATA3 _2
SATA3 _1
COM1
1
25
CHA_FAN2/WP
M2_1
C 3
C 2
T
T
C 4
T
C 1
T
27
26
CHA_FAN4/WP
USB 3.2 Gen1
T: USB3_3
B: USB3_4
HDMI1
1
SPI_TPM_J1
11
AMD
B550

ASROCK PHANTOM GAMING 4 B550 Specifications

General

Chipset	AMD B550
CPU Socket	AM4
Form Factor	ATX
Maximum Memory	128GB
SATA 6Gb/s Ports	6
RAID Support	RAID 0, 1, 10
Memory Slots	4
M.2 Slots	2
USB 3.2 Gen2 Ports	2
LAN	Gigabit Ethernet
Audio	Realtek ALC1200 7.1-Channel High Definition Audio
Memory Speed	DDR4 4733MHz (OC)
Multi-GPU Support	AMD CrossFireX
PCIe Slots	2 x PCIe 4.0 x16, 2 x PCIe 3.0 x1
