5-30 Chapter 5: RAID conguration
5.3 Intel
®
Matrix Storage Manager
Option ROM Utility
The Intel
®
Matrix Storage Manager Option ROM utility allows you to create RAID 0,
RAID 1, RAID 0+1, and RAID 5 set(s) from Serial ATA hard disk drives.
To enter the Intel
®
Matrix Storage Manager Option ROM Utility:
1. Turn on the system after installing all Serial ATA hard disk drives.
2. During POST, press <Ctrl+I> to display the utility main menu.
The navigation keys at the bottom of the screen allow you to move through
the menus and select the menu options.
The RAID setup screens shown in this section are for reference only and
may not exactly match the items on your screen due to the controller version
difference.
Intel(R) Matrix Storage Manager Option ROM v5.0.0.1032 ESB2 wRAID5
Copyright(C) 2003-05 Intel Corporation. All Rights Reserved.
[ MAIN MENU ]
1. Create RAID Volume
2. Delete RAID Volume
3. Reset Disks to Non-RAID
4. Exit
[ DISK/VOLUME INFORMATION ]
RAID Volumes:
Nonedened.
Physical Disks:
Port Drive Model Serial # Size Type/Status(Vol ID)
0 XXXXXXXXXXX XXXXXXXX XX.XXGB
Non-RAID Disk
1 XXXXXXXXXXX XXXXXXXX XX.XXGB
Non-RAID Disk
2 XXXXXXXXXXX XXXXXXXX XX.XXGB Non-RAID Disk
3 XXXXXXXXXXX XXXXXXXX XX.XXGB Non-RAID Disk
[
↑↓
]-Select [ESC]-Exit [ENTER]-Select Menu
The utility supports maxium four hard disk drives for RAID congurration.
