5.5.3 Integrated Striping (IS) volume
Overview
The Integrated Striping (IS) feature provides RAID 0 functionality, supporting
volumes with two to eight disks. You may combine an IS volume with an IM or IME
volume.
Creating Integrated Striping volumes
DO NOT combine Serial ATA and SAS disks in one volume.
To create an IS volume:
1. Turn on the system after installing all SAS hard disk drives.
2. During POST, press <Ctrl+C> to enter the SAS conguration utility.
3. The
Adapter Properties
screen appears.
Use the arrow keys to select
RAID Properties
, then press <Enter>.
LSI Logic Corp. MPT SAS BIOS
MPTBIOS-6.08.05.00 (2006.08.02)
Copyright 2000-2006 LSI Logic Corp.
Adapter(s) disabled by user
PressCtrl-CtostartLSILogicCongurationUtility...
Esc = Exit Menu F1/Shift+1 = Help
Enter = Select Item -/+ = Change Item
LSILogicCongUtilityv6.08.05.00(2006.08.02)
Adapter Properties -- SAS1068
Adapter SAS1068
PCI Slot 00
PCI Address(Bus/Dev/Func) 05.03.00
MPT Firmware Revision 1.15.00.00-IR
SAS Address 500E0180:60831008
NVIDIA Version 25.02
Status Disabled
Boot Order 0
Boot Support
(Enabled OS only)
RAID Properties
SAS Topology
Advanced Adapter Properties
