1-26 Chapter 1: Quick Start
• DO NOT attach the external AC power when connecting the power
connectors to the motherboard.
• Ensure the power connectors are rmly secured to the motherboard.
• If your power supply supports 20-pin+4-pin, you are able to combine these
two connectors and install to the 24-pin connectors on the motherboard.
Power connectors
20+4 (24) pin ATX connector
4-pin ATX connector
peripheral power connector (left)
oppypowerconnector(right)
