4-14 Chapter 4: Software support
Chapter 4
4.3.8 Sensor Recorder
Sensor Recorder allows you to monitor the changes in the system voltage, temperature, and
fan speed, as well as recording the changes.
Launching Sensor Recorder
After installing AI Suite II from the motherboard support DVD, click Tool > Sensor
Recorder on the AI Suite II main menu bar to launch PC Probe II.
Conguring Sensor Recorder
Click the Voltage/Temperature/Fan Speed tabs and select the sensors that you want to
monitor. The History Record tab allows you to record the changes in the sensors that you
enable.
Select the
sensors that you
want to monitor
Click to zoom in/out
the Y axis
Click to zoom in/out
the X axis
Click to return to
the default mode
Drag to view the
status during a
certain period
of time

Asus P8P67 Specifications

General

Chipset	Intel P67
Socket	LGA 1155
Memory Slots	4 x DIMM
Maximum Memory	32GB
Memory Type	DDR3
PCI Express x16	2
PCI Express x1 Slots	2
PCIe 3.0 x16	No
PCIe 2.0 x16	2
PCIe 2.0 x1	2
PCI Slots	3
SATA Ports	4 x SATA 3Gb/s, 2 x SATA 6Gb/s
USB Ports	14
USB 2.0 Ports	12
USB 3.0 Ports	2
Form Factor	ATX
Audio	Realtek ALC892 8-Channel High Definition Audio CODEC
LAN	Realtek 8111E
