Asus P8P67 User Manual

2-42 Chapter 2: Hardware information
Chapter 2
2.3.10 Rear panel connection
Rear panel connectors
1. PS/2 mouse port (green) 7. USB 2.0 ports 5 and 6
2. Optical S/PDIF Out port 8. USB 2.0 ports 3 and 4
3. Bluetooth module* 9. USB 2.0 ports 1 and 2
4. IEEE 1394a port 10. USB 3.0 ports 1 and 2
5. LAN (RJ-45) port** 11. Audio I/O ports***
6. PS/2 keyboard port (purple)
• Due to USB 3.0 controller limitation, USB 3.0 devices can only be used under
Windows
®
OS environment and after the USB 3.0 driver installation.
• USB 3.0 devices can only be used as data storage only.
• We strongly recommend that you connect USB 3.0 devices to USB 3.0 ports for faster
and better performance for your USB 3.0 devices.
*, ** and ***: Refer to the tables on the next page for bluetooth module LED, LAN port LED, and
audio port denitions.

Asus P8P67 Specifications

General

Chipset	Intel P67
Socket	LGA 1155
Memory Slots	4 x DIMM
Maximum Memory	32GB
Memory Type	DDR3
PCI Express x16	2
PCI Express x1 Slots	2
PCIe 3.0 x16	No
PCIe 2.0 x16	2
PCIe 2.0 x1	2
PCI Slots	3
SATA Ports	4 x SATA 3Gb/s, 2 x SATA 6Gb/s
USB Ports	14
USB 2.0 Ports	12
USB 3.0 Ports	2
Form Factor	ATX
Audio	Realtek ALC892 8-Channel High Definition Audio CODEC
LAN	Realtek 8111E
