3-20 Chapter 3: BIOS setup
Chapter 3
3.5.6 Onboard Devices Conguration
HD Audio Controller [Enabled]
[Enabled] Enables the High Denition Audio Controller.
[Disabled] Disables the controller.
The following two items appear only when you set the Azalia HD Audio item to [Enabled].
Front Panel Type [HD]
Allows you to set the front panel audio connector (AAFP) mode to legacy AC’97 or high-
denition audio depending on the audio standard that the front panel audio module supports.
[HD] Sets the front panel audio connector (AAFP) mode to high denition audio.
[AC97] Sets the front panel audio connector (AAFP) mode to legacy AC’97
SPDIF Out Type [SPDIF]
[SPDIF] Sets to [SPDIF] for SPDIF audio output.
[HDMI] Sets to [HDMI] for HDMI audio output.
Renesas Electronics USB 3.0 [Enabled]
[Enabled] Enables the USB 3.0 controller.
[Disabled] Disables the controller.
Main
Ai Tweaker
Advanced Monitor Boot Tool
Exit
Version 2.00.1201. Copyright (C) 2010 American Megatrends, Inc.
Enabled/Disabled Azalia HD Audio
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save ESC: Exit
Back Advanced\ Onboard Devices Conguration >
EFI BIOS Utility - Advanced Mode
HD Audio Controller Enabled
Front Panel Type HD
SPDIF Out Type SPDIF
Renesas Electronics USB 3.0 Enabled
VIA 1394 Enabled
PCI Express x16_2 slot (Black) bandwidth Auto
Marvell Storage Controller AHCI Mode
Marvell Storage OPROM Enabled
Realtek LAN Controller Enabled
Realtek PXE OPROM Disabled
> Serial Port Conguration

Asus P8P67 Specifications

General

Chipset	Intel P67
Socket	LGA 1155
Memory Slots	4 x DIMM
Maximum Memory	32GB
Memory Type	DDR3
PCI Express x16	2
PCI Express x1 Slots	2
PCIe 3.0 x16	No
PCIe 2.0 x16	2
PCIe 2.0 x1	2
PCI Slots	3
SATA Ports	4 x SATA 3Gb/s, 2 x SATA 6Gb/s
USB Ports	14
USB 2.0 Ports	12
USB 3.0 Ports	2
Form Factor	ATX
Audio	Realtek ALC892 8-Channel High Definition Audio CODEC
LAN	Realtek 8111E
