Asus ROG SWIFT PRO User Manual

2-3ASUS ROG Swift Pro PG248QP Series LCD Monitor
2.4 Detaching the arm (for VESA wall
mount)
The detachable arm of this monitor is specially designed for VESA wall mount.
To detach the arm:
1. Have the front of the monitor face down on a table.
2. Use a screwdriver to remove the covers on where the monitor and the arm
meet (Figure 1 & Figure 2).
3. Loosen the four screws on the back of the monitor and remove the arm/base
(Figure 3 & Figure 4).
1 2 3 4
We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.
• The VESA wall mount kit (100 x 100 mm) is purchased separately.
• Use only the UL Listed Wall Mount Bracket with minimum weight/load
22.7kg (Screw size: M4 x 10 mm)
