Asus RT-N10 User Manual

17
AP Mode
To set up your wireless router in AP mode:
1. Connect your devices.
Use an Ethernet cable (wired connection) to connect your
computer to the wireless router for initial configuration to avoid
possible wireless setup problems.
In AP mode, the wireless router receives the WAN IP address from
the router connected to the WAN port and provides a wireless
radio signal for your network. NAT, firewall, IP sharing services are
disabled.
Modem
Router
Client
RT-N10

Asus RT-N10 Specifications

General

Wireless Standard	IEEE 802.11b/g/n
Frequency Band	2.4 GHz
Data Rate	Up to 150 Mbps
LAN Ports	4 x 10/100 Mbps
WAN Ports	1 x 10/100 Mbps
WPS	Yes
Security	WEP, WPA, WPA2
Antennas	1 x external
