Asus X99-E-10G WS User Manual

3-40
Chapter 3: BIOS Setup
Chapter 3
The following items appear only when you set the SATA Controller 1 Mode Selection to
[RAID] or [AHCI].
Support Aggressive Link Power Management [Disabled]
This item is designed for LPM (link power management) support with a better energy saving
conditions. When set to [Enabled], the hot plug function of SATA ports are disabled.
Conguration options: [Disabled] [Enabled]
SATA6G_1(Gray) - SATA6G_6(Gray)
SATA6G_1(Gray) - SATA6G_6(Gray) [Enabled]
This item allows you to enable or disable the selected SATA port.
Conguration options: [Disabled] [Enabled]
Hot Plug [Disabled]
These items allows you to enable or disable SATA Hot Plug Support.
Conguration options: [Disabled] [Enabled]
SATA Controller 2
SATA Controller 2 Mode Selection [AHCI]
This item allows you to set the SATA conguration.
[Disabled] Disable the SATA function.
[IDE] Use SATA hard disk as Parallel ATA storage devices
[AHCI] Set to [AHCI] when you want the SATA hard disk drives to use the AHCI
(Advanced Host Controller Interface). The AHCI allows the onboard storage
driver to enable advanced Serial ATA features that increases storage
performance on random workloads by allowing the drive to internally
optimize the order of commands.
Due to Intel
®
chipset specication, the SATA ports from controller 2 does not support Intel
®
Rapid Storage Technology including RAID conguration.
The following item appears only when you set the SATA Controller 2 Mode Selection to
[AHCI].
Support Aggressive Link Power Management [Disabled]
This item is designed for LPM (link power management) support with a better energy saving
conditions. When set to [Enabled], the hot plug function of SATA ports are disabled.
Conguration options: [Disabled] [Enabled]

Asus X99-E-10G WS Specifications

General

ECC	Yes
Memory channels	Quad-channel
Memory slots type	DIMM
Number of memory slots	8
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	2133, 2400, 2666, 2800, 3000, 3200, 3333 MHz
HDD size	2.5/3.5 \
PCI Express power connectors (6-pin)	1
Processor socket	LGA 2011-v3
Intel Xeon series	E5-1600, E5-2600
Processor manufacturer	Intel
Compatible processor series	Intel® Xeon®
Graphics card family	AMD, NVIDIA
Parallel processing technology support	4-Way CrossFireX, 4-Way SLI
RAID levels	0, 1, 5, 10
Number of HDDs supported	10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	SATA III
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
BIOS type	UEFI AMI
ACPI version	5.0
BIOS memory size	16 Mbit
Desktop Management Interface (DMI) version	2.7
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Wi-Fi	No
LAN controller	Intel® X550
Ethernet interface type	Gigabit Ethernet
Cables included	SATA
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	20 - 90 %
Audio chip	Realtek ALC1150
Component for	Workstation
Motherboard chipset	Intel® X99
Audio output channels	7.1 channels
Motherboard form factor	CEB
PCI Express x16 (Gen 3.x) slots	7

Weight and Dimensions

Depth	267 mm
Width	305 mm
