4.4.7 DIGI+ Power Control
ASUSDIGI+PowerControlfeaturestherevolutionaryandinnovativedigitalVRMandDRAM
Voltagecontrollers.Thesecontrollersoffersultra-precisememoryandvoltagetuningfor
optimalsystemefciency,stabilityandperformance.
Thefollowingscreensareforreferenceonly.Congurationoptionsvariesdependingonthe
motherboardmodel.
Launching DIGI+ Power Control on your computer
TolaunchDIGI+PowerControl,clickortap onthetop-rightcorneroftheAISuite3main
menu,thenselectDIGI+ Power Control.
Adjusting the CPU Power
CPU Power Phase Control
Increasethephasenumberunderaheavysystemloadtogetmoretransientand
betterthermalperformance.Reducethephasenumberunderalightsystemload
toincreasetheVRMefciency.
CPU VRM Switching Frequency
Enablesspreadspectrumtoenhancesystemstability.
CPU Load-line Calibration
ItallowsyoutoadjustthevoltagerangetocontroltheCPULoad-line.Adjusttoa
highvalueforsystemperformanceortoalowvalueforpowerefciency.
CPU Current Capability
CPUCurrentCapabilityprovidesawidertotalpowerrangeforoverclocking.
Ahighervaluebringsawidertotalpowerrangeandextendstheoverclocking
frequencyrangesimultaneously.
CPU Power Thermal Control
AhighertemperaturebringsawiderCPUpowerthermalrangeandextendsthe
overclockingtolerancetoenlargetheoverclockingpotential.
Click or tap to switch
between screens
Click or tap to
apply the changes
Click or tap to undo
the changes
