Asus Z97-P User Manual

ASUS Z97-P
1-3
1.2.3 Motherboard layout
Z97-P
PCIEX16_1
PCIEX16_2
PCIEX1_1
PCIEX1_2
ASM
1083
PCI1
PCI2
USB910 USB1112 USB1314
AAFP
EATXPWR
CPU_FAN CHA_FAN2
BATTERY
Super
I/O
ALC
891
RTL
8111GR
ASM
1442K
KBMS
DVI_VGA
CLRTC
21.3cm(8.4in)
Intel
®
Z97
DDR3 DIMM_A1 (64bit, 240-pin module) DDR3 DIMM_A2 (64bit, 240-pin module) DDR3 DIMM_B1 (64bit, 240-pin module) DDR3 DIMM_B2 (64bit, 240-pin module)
SATA6G_3SATA6G_4
SPEAKER
SATA6G_1SATA6G_2
AUDIO
LAN_USB78
USB3_56
USB3_34
HDMI
CHA_FAN1
SPDIF_OUT
30.5cm(12.0in)
LGA1150
DIGI
+VRM
COM
EATX12V
USB3_12
TPM
M.2(SOCKET3)
64Mb
BIOS
F_PANEL
2 31 41
1015 911 5121314
2
5
8
6
7

Asus Z97-P Specifications

General

Form Factor	ATX
Chipset	Intel Z97
Socket	LGA 1150
Memory Slots	4
Maximum Memory	32GB
Memory Type	DDR3
PCIe x16 Slots	2
PCIe x1 Slots	2
PCI Slots	2
Audio	Realtek ALC887 8-Channel High Definition Audio CODEC
LAN	Realtek 8111GR, 1 x Gigabit LAN Controller(s)
RAID Support	Yes
Memory Standard	DDR3 3200(O.C.)/3100(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666(O.C.)/2400(O.C.)/2200(O.C.)/2133(O.C.)/1866(O.C.)/1600/1333 MHz
SATA Express Ports	1 x SATA Express
M.2 Slot	1
USB 2.0 Ports	8 x USB 2.0
Multi-GPU Support	AMD Quad-GPU CrossFireX Technology
USB 3.0 Ports	4 x USB 3.0 (2 at back panel, 2 at mid-board)
