2.2.4 EZ Tuning Wizard
EZ Tuning Wizard allows you to overclock your CPU and DRAM, computer usage, and CPU
fan to their best settings. You can also easily set RAID in your system using this feature.
Tuning your system settings
To tune your settings:
1. Press <F11> on your keyboard or click
from the BIOS screen to open
EZ Tuning Wizard screen, then click Next.
2. Select a PC scenario Daily Computing or Gaming/Media Editing, then click Next.
3. Select the CPU fan type (Box cooler, Tower cooler, or Water cooler) that you
installed then click Next.
If you are not sure of the CPU fan type, click I’m not sure. The system automatically
detects the CPU fan type.
4. Click Next then click Yes to conrm auto‑tuning.
System OC setup RAID setup
ASUS Z97-P 2‑13

Asus Z97-P Specifications

General

Form Factor	ATX
Chipset	Intel Z97
Socket	LGA 1150
Memory Slots	4
Maximum Memory	32GB
Memory Type	DDR3
PCIe x16 Slots	2
PCIe x1 Slots	2
PCI Slots	2
Audio	Realtek ALC887 8-Channel High Definition Audio CODEC
LAN	Realtek 8111GR, 1 x Gigabit LAN Controller(s)
RAID Support	Yes
Memory Standard	DDR3 3200(O.C.)/3100(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666(O.C.)/2400(O.C.)/2200(O.C.)/2133(O.C.)/1866(O.C.)/1600/1333 MHz
SATA Express Ports	1 x SATA Express
M.2 Slot	1
USB 2.0 Ports	8 x USB 2.0
Multi-GPU Support	AMD Quad-GPU CrossFireX Technology
USB 3.0 Ports	4 x USB 3.0 (2 at back panel, 2 at mid-board)
