Revision A
22
A-1. SPECIFICATIONS
Dimensions (L x W x H)
13.5 in x 9.5 in x 5.0 in
34.3 cm x 24.0 cm x 12.7 cm
Weight
2H Aerosol Photometer (standard use) 15.5 lbs (7.0 kg)
2H-N Aerosol Photometer (nuclear use) 15.5 lbs (7.0 kg)
TDA-2SP Scanning Probe 2.5 lbs (1.1 kg)
Input Power
90 to 250 volts AC, 50 or 60 Hz, 1.5 amps
Fuse
250 volts, 2.0 amps slow blow (5 x 20 mm)
Dynamic Range
0.00005 to 120 micrograms per liter
Accuracy
1% of full-scale for the amplifier decade range in use
Repeatability
0.5% full-scale for the amplifier decade range in use
Sampling Rate
1 CFM (28.3 LPM)
Data Output
RS-232: Port settings: 2400, 8, N, 1 (Continuous output)
RS-232 Cable Requirement
A straight-through DB-9 serial cable is required. ATI part number T2G0-1120 or equivalent.
