1 INSTALLATION QUALIFICATION
1.1 REQUIREMENTS
NOTE: High ambient temperatures may create instability in the readings.
The 2H requires the following for proper operation:
• Stable electrical power at 90/240 VAC, single phase, 50/60 Hz, 5 amps.
• Environment Operating Range: 35° to105° Fahrenheit (1.6° to 40.6° Celsius)
with less than 75% relative humidity.
1.2 UNPACKING
NOTE: Save all packaging material for future use.
Carefully unpack and remove the 2H Aerosol Photometer and all accessories from its shipping
container. If the instrument has been damaged in transit, notify the shipper immediately.
Make sure the following items are included with both the 2H (9300133) and the 2HHP (9300134):
1) 1 power cord, 6700001 (120 VAC) or T2E0-0063 (220 VAC)
2) 12 feet of clear PVC tubing, 5200116
3) Operating Manual, 1800110
4) Calibration certificate
The following items are optional. Check the order packing slip.
1) Shipping case, 9300145
2) 2H-SP Scanning Probe, complete, 9300144
a) 1 round isokinetic nozzle (red), T2E0-0572
b) 1 rectangular isokinetic nozzle (blue), T2E0-0798
c) 1 NSF 1” round nozzle (black), T2E0-0005
d) 1 Scanning probe, T2SP-0881
If any of these items are on the order packing slip but missing from the shipment, contact ATI
immediately at:
Air Techniques International
Division of Hamilton Associates
11403 Cronridge Drive
Owings Mills, Maryland 21117-2247 U.S.A.
Tel: 410 363-9696 Fax: 410 363-9695
www.atitest.com
Revision A
6
