Text on image
(1) General (4) General warning
(2) General shutdown (5) Cabinet fan
(3) Fan motor
• The screen shows a list of all outputs with their corresponding icons and readings.
If an output is in warning or shutdown, the original icon is replaced by the warning or
shutdown icon respectively.
3.10
Counters
Menu icon, Counters
Function
To call up:
•
The running hours
• The loaded hours
• The number of motor starts
• The number of hours that the regulator has been powered
• The number of load cycles
Procedure
Starting from the Main screen,
• Using the Scroll keys, move the cursor to the action button Menu and press the Enter key.
Following screen appears:
Text on image
(1) Menu (2) Regulation
• Using the Scroll keys, move the cursor to the Counters icon (see above).
•
Press the Enter key. Following screen appears:
Instruction book
2920 7140 52 43
