User guide EN TPS Control
42
© Atlas Copco Industrial Technique AB - 9836 5819 01
Parameter name Description Range/Values
Counted from Id2 position to be counted from; either the head or the
tail of the barcode string
head, tail
Default: head
Define new code
Parameter name Description Range/Values
Start position Sets start position from where identification of the bar-
code should start.
1-255
Default: 1
Start counting from Determines whether counting should start from begin-
ning or end of a barcode.
head, tail
Default: head
Code Specifies the characters in the barcode that, if found,
trigger a job to start.
A-Z, a-z, 0-9
Job number Sets the job to start when the specified character code
is found in a barcode
1-63
Default: 1
Service
Parameter name Description Range/Values
User language Selects the language used in the operating dialogue.
Possible options are English, German and French.
English
Deutsch
Francais
Default: English
System information Gives information regarding Device ID, software ver-
sion and version number of the I/O modules and the
enabled options
Print out Opens the submenu containing the printing functions
Test functions Opens the submenu containing the test functions
Reset parameter +
jobs
Resets all setup parameters to the factory settings and
deletes all jobs.
Reset jobs only Deletes all jobs, but keeps the parameter settings.
Reset system Restarts the TPS Control system (according to the
power-on cycle)
Licence keys Activates optional functions (in a separate submenu).
Activation codes can be ordered from Atlas Copco us-
ing the unit device ID
Firmware update Prepares the unit for a firmware update through the
serial interface.
Print-Out
Parameter name Description Range/Values
Print parameters Prints a plain text list of all setup parameters on the
serial interface
Print jobs Prints a plain text list of all jobs on the serial interface
Print all Prints all parameters and all jobs on the serial inter-
face
