4.5 Pictographs

Pictographs

Reference Name

1 Pictograph, Automatic start - Read manual - No service with voltage and pressure on

2 Pictograph, warning: blow off

3 Pictograph, warning: under tension

4 Pictograph, warning: hot surface

5 Pictograph, transport instructions

6 Stop the unit before maintenance or repair

7 Pictograph, earthing

8 Rotation direction arrow

9 Only use Roto-Z oil

10 Check the air flow direction

Instruction book

AIF999999 55
