9 Technical data
9.1 Readings
Important
The readings below are valid when operating at reference conditions. See Reference
conditions.
Readings on display
For the maximum working pressure, consult section Machine data.
The readings depend on the unit type. The values given below are average values and may differ
depending on the unit type.
Item Reading
Outlet pressure Depends on unit type
dp of air filter Below -0.044 bar
Oil pressure 2.5 bar(e)
Air outlet temperature 98 ˚C
Oil temperature Approx. 40 ˚C
9.2 Settings for overload relay and fuses
Settings for overload relays and fuses are available in the electrical diagram.
9.3 Reference conditions and limitations
Reference conditions
Item Condition
Absolute inlet pressure 1 bar(a)
Relative air humidity 0 %
Air inlet temperature 20 ˚C
Nominal effective working pressure 1.2 bar
