vii

List of Tables

Table 2.1: LEDs and Buttons.............................................................................................................5

Table 2.2: Physical Interface and Connector Summary....................................................................6

Table 2.3: RS-232 Serial Port Pin Assignments ................................................................................7

Table 2.4: RS-422 and RS-485 Serial Port Pin Assignments ............................................................8

Table 2.5: Ethernet Connector Pin Assignments...............................................................................9

Table 2.6: ESP Serial Hub Electrical Connectors ..........................................................................10

Table 2.7: When Changes Take Effect.............................................................................................12

Table 3.1: Serial Port Redirection Configurable Items...................................................................16

Table 3.2: Telnet Server Connection Method Configurable Items..................................................17

Table 3.3: Raw TCP Server Connection Method Configurable Items ............................................18

Table 3.4: Raw TCP Client Connection Method Configurable Items .............................................19

Table 3.5: Modem Emulation Connection Method Configurable Items .........................................21

Table 3.6: Modem Commands.........................................................................................................24

Table 3.7: Modem Command Response Codes ...............................................................................26

Table 3.8: Dialout Translation Set ..................................................................................................27

Table 3.9: Configuration Utility Connection Method Configurable Items .....................................28

Table 3.10: Serial Port Valid and Default Values ..........................................................................29

Table 3.11: Configurable Features .................................................................................................29

Table 4.1: Reference to Connection Method Rules and Values ......................................................34

Table 4.2: General Statistics Display..............................................................................................38

Table 4.3: Port Statistics Display....................................................................................................39

Table 4.4: Serial Port Active Connection Status Display................................................................39

Table 4.5: Serial Port Redirection Connections Status Display .....................................................40

Table 5.1: Reference to Connection Method Rules and Values ......................................................47

Table 6.1: Configurable Features Commands ................................................................................59

Table 7.1: ESP-Install Program Commands...................................................................................64

LIST OF TABLES

Avocent ESP Serial Hub User Manual
