Adjusting
46
Ensure that the space above the head
restraints is clear, otherwise persons
could be injured or objects damaged when the
head restraints are extended.<
You can use the safety switch, see
page 38, to deactivate head restraint
height adjustment.<
Removing and installing: as for front head
restraints, electric.
Centre head restraint
Pull out the retracted head restraint until it
engages in position before the centre rear
seat is occupied. Otherwise its protective effect
will be impaired.<
Rear: adjusting side sections*
Fold the head restraint's side sections forward
to provide greater lateral support in the rest
position.
Seat belts
Comply with the notes on page 41, or
there may be a risk to your personal
safety.<
All occupants should always fasten their seat
belt before you set off. The airbags are a com-
plementary safety feature and not a substitute
for the seat belts.
Fastening
The seat belt buckle must be heard to engage.
Unfastening
1. Hold onto the belt.
2. Press the red button on the belt buckle.
3. Guide the belt back up to the reel.
The upper belt anchorage is suitable for adults
of any stature as long as they are sitting cor-
rectly, see page 41.
The two seat belt buckles integrated into the
rear seat are intended for the left and right seat
occupants. The buckle marked CENTER is only
to be used by a person occupying the centre
rear seat.
Belt reminder for driver's and front
passenger's seat*
Indicator light on the info display lights
up and a signal sound is generated. In
addition, a message will appear on the
info display. Please check whether the seat belt
is fastened correctly.
The belt reminder is issued as long as the
driver's seat belt has not been fastened. On cer-
tain national-market versions, the belt reminder
Online Edition for Part no. 01 41 0 013 197 - © 02/07 BMW AG
