BMW C 400 X User Manual

NOTICE
The operation described here for
the left fairing side panel applies
analogously to the right side.
Lift the fairing side panel 2
slightly at the edges.
Pull the mounting clips 3 of the
fairing side panel 2 as evenly
as possible out of the mounts.
Install fairing side panel
Check whether all mounting
clips 3 are installed on the fair-
ing side panel 2.
Position the fairing side panel 2
and push the mounting clips 3
evenly into the mounts.
NOTICE
The operation described here for
the left fairing side panel applies
analogously to the right side.
Install the screws 1 for the fair-
ing side panel.
Data link connector
Removing the diagnostic
connector
Requirement
The data link connector is lo-
cated under the battery compart-
ment cover by the leg shield.
Remove battery cover ( 166).
10
167
z Maintenance
https://www.motorcycle-manual.com/

BMW C 400 X Specifications

General

Displacement	350 cc
Transmission	CVT
Fuel System	Electronic Fuel Injection
Front Suspension	Telescopic fork
Front Brake	Single disc, 265 mm
Rear Brake	Single disc, 265 mm
ABS	Standard
Front Tire	120/70 R15
Rear Tire	150/70 R14
Seat Height	775 mm
Fuel Capacity	12.8 liters
Width	835 mm
Engine Type	Single-cylinder, four-stroke
Max Power	34 hp (25 kW) @ 7, 500 rpm
Max Torque	35 Nm
Rear Suspension	Double swingarm
Weight	204 kg
Length	2, 210 mm
Height	1, 305 mm
Wheelbase	1, 565 mm
