BMW C 400 X User Manual

Indicator lights with
connectivity
Displays
Warnings are displayed with ap-
propriate warning lights.
Warnings are indicated by the
general warning light in conjunc-
tion with a dialog in the TFT
display. The universal warning
light lights up in either yellow or
red depending on the urgency of
the warning.
The universal warning light
lights up for the most ur-
gent warning.
You will find an overview of the
potential warnings on the follow-
ing pages.
Check Control display
The messages in the display are
shown differently in the display.
Different colors and characters
are used depending on the prior-
ity:
Green CHECK OK 1: no mes-
sage, values optimal.
White circle with small "i" 2:
information.
Yellow warning triangle 3:
warning message, value not
optimal.
Red warning triangle 3: warn-
ing message, value critical
Value display
The symbols 4 differ in their
display. Different colors are used
depending on the assessment of
value. Instead of numerical val-
ues 8 with units 7, texts 6 are
also displayed:
Color of the symbol
Green: (OK) current value is
optimal.
Blue: (Cold!) current tempera-
ture is too low.
Yellow: (Low! /High!) current
value is too low or too high.
Red: (Hot! /High!) current tem-
perature or value is too high.
3
40
z Displays
https://www.motorcycle-manual.com/

BMW C 400 X Specifications

General

Displacement	350 cc
Transmission	CVT
Fuel System	Electronic Fuel Injection
Front Suspension	Telescopic fork
Front Brake	Single disc, 265 mm
Rear Brake	Single disc, 265 mm
ABS	Standard
Front Tire	120/70 R15
Rear Tire	150/70 R14
Seat Height	775 mm
Fuel Capacity	12.8 liters
Width	835 mm
Engine Type	Single-cylinder, four-stroke
Max Power	34 hp (25 kW) @ 7, 500 rpm
Max Torque	35 Nm
Rear Suspension	Double swingarm
Weight	204 kg
Length	2, 210 mm
Height	1, 305 mm
Wheelbase	1, 565 mm
