BMW C 400 X User Manual

Mount topcase
Be sure that the topcase han-
dle 2 is folded out and that the
key in the topcase lock is in
the RELEASE position.
Insert the topcase in the top-
case carrier in the front.
Pull the release lever 4 toward
the back while inserting the
topcase in the topcase carrier
from the back.
Close the topcase handle 2.
If necessary, turn key in Top-
case lock to the CLOSE posi-
tion and remove.
Maximum payload
Observe the maximum payload
on the sign in the topcase.
If you cannot find your combina-
tion of motorcycle and topcase
on the label, contact your BMW
Motorrad Retailer.
The following values apply to the
combination described here:
Payload of Topcase
max 11 lbs (max 5 kg)
Navigation system
Install navigation device
with navigation system
OA
Place the navigation device 1
in the mount 2.
Pivot the navigation device 1
forward and press the upper
edge into the detent 3.
The navigation device engages.
11
173
z Accessories
https://www.motorcycle-manual.com/

BMW C 400 X Specifications

General

Displacement	350 cc
Transmission	CVT
Fuel System	Electronic Fuel Injection
Front Suspension	Telescopic fork
Front Brake	Single disc, 265 mm
Rear Brake	Single disc, 265 mm
ABS	Standard
Front Tire	120/70 R15
Rear Tire	150/70 R14
Seat Height	775 mm
Fuel Capacity	12.8 liters
Width	835 mm
Engine Type	Single-cylinder, four-stroke
Max Power	34 hp (25 kW) @ 7, 500 rpm
Max Torque	35 Nm
Rear Suspension	Double swingarm
Weight	204 kg
Length	2, 210 mm
Height	1, 305 mm
Wheelbase	1, 565 mm
