BMW CE 04 User Manual

160 MAINTENANCE
Turn off standby mode.
Park the E-Scooter, making
sure it is on level and firm
ground.
Removing side trim panel
( 155).
Replace faulty fuse 1.
If the fuses blow
frequently, have the
electrical system checked
by an authorized specialized
workshop, preferably an
authorized BMW Motorrad
retailer.
Main fuse
40 A (Main fuse)
Installing side trim panel
( 155).
Replacing fuses
Turn off standby mode.
Removing side trim panel
( 155).
Pull off the fuse box 1.
ATTENTION
Bypassing defective fuses
Risk of short circuit and fire
Do not bypass defective
fuses.
Replace defective fuses with
new fuses.
Replace the faulty fuse 1 to 8
according to their assignment.

BMW CE 04 Specifications

General

Motor Power	31 kW (42 hp)
Battery Capacity	8.9 kWh
Top Speed	120 km/h (75 mph)
Rated Power	15 kW (20 hp)
Front Suspension	Telescopic fork
Rear Suspension	Single-sided swing arm
ABS	Standard
Traction Control	Standard
Wheelbase	1, 675 mm (65.9 inches)
Range	130 km
Charging Time	4 hours 20 minutes (0-100%)
Seat Height	780 mm
Motor Type	Liquid-cooled electric motor
Front Brake	Twin disc brake
Rear Brake	Single disc brake
Torque	62 Nm
Length	2, 285 mm
Width	855 mm
Height	1, 150 mm
Weight	231 kg
