If the fuses blow
frequently, have the
electrical system checked
by an authorized specialized
workshop, preferably an
authorized BMW Motorrad
retailer.
Fuse 1
15 A (EME, relay terminal 30
switched)
Fuse 2
7.5 A (Terminal 30B, EME,
Antilock Braking System
(ABS), sensor box, seat
heating, USB charging
compartment, TPM, storage
compartments)
Fuse 3
10 A (EME)
Fuse 4
7.5 A (Terminal 30, cut-off
relay terminal 30B, anti-theft
alarm system, vehicle lock,
instrument cluster, on-board
charger, diagnostic connec-
tor)
Fuse 5
7.5 A (Terminal 30C, mul-
tifunction switch left, high-
voltage safety plug, EME, on-
board charger)
Fuse 6
Not in use
Fuse 7
Not in use
Fuse 8
Not in use
Insert the fuse box.
Installing side trim panel
( 155).
